ORCA v6

The ORCA v6 rebreather offers extended duration dives, excellent freedom of movement, stable buoyancy and unique safety features. In a compact, easy to use package.

Orca v6_thumbnail.png
Brochure

Explore the operational details technical specification of this rugged product in a downloadable brochure.

Exploration in Action

In a video shot exclusively by Martin Robson Diving, explore cave diving in Florida with the Lungfish Orca CCR. Thanks Martin!


OVERALL DIMENSIONS

60cm X 40cm X 20cm.

Central unit 32cm X 30cm X 20cm



WEIGHT

BARE WEIGHT: (without cylinders or CO2 absorbent) ~ 11 KG

TRANSPORT WEIGHT: (without cylinders, CO2 absorbent or electronics) ~ 10 KG

DIVING WEIGHT: (with Absorbent & Standard Cylinders) ~ 18 Kg

BUOYANCY: Unit alone ~ 2Kg negative. Standard Buoyancy Compensator 16 Kg lift.



GAS SUPPLY

Lungfish offer our own 2l 200 bar steel cylinders with valves if required

Offboard gas connections as standard

Larger cylinders can be fixed to sides or hung as side mounts.

CO2 SCRUBBER

2.2Kgs Sofnolime 797 or Divelime 812. Duration 3 hours+



SENSORS

Standard 3 O2 sensors, 1 CO2 sensor.

Optional 4th independent O2 sensor.

Depth sensor 0-130msw.



CONTROL SYSTEM

Electronic and manual PPO2 control system as standard.



OPTIONS

Multiple Isolated outputs to additional displays and computers.

Standard or wide-screen display

Multiple cylinder and gas supply configuration options.

Extreme conditions kit.

Many more .....

The Orca v6 Rebreather has been CE and UKCA certified by 0598 and 0120 and. It is classified as Category III Personal Protective Equipment and therefore falls under the EU Directive 425/2016.  It has been tested in accordance with EN 14143:2013 to 100 msw in cold water at 4 degrees C.
